1. Introduction of product function
l Satisfaction of the requirements of new energy GB/T32960
l Satisfaction of the requirements of the limits and measurement methods for emissions from diesel fueled heavy-duty vehicles (China VI) GB 17691
l 4G all Netcom
l GPS/BD positioning
l Remote OTA
l Hardware encryption
l TF card/eMMC storage
l WiFi/Bluetooth;
l G-Sensor collision warning
l Remote diagnosis and remote control
l Cloud platform management
2. Introduction of product performance
l Communication level Cat4；
l Support frequency band LTE, 3G and GSM
l Positioning module: GPS + BD positioning
l Positioning accuracy<2.5m；
l Standby battery：550mAH/3.6V；
3. Advantages of product solution
l Satisfaction of requirements of GB/T32960 new energy and the limits and measurement methods for emissions from diesel fueled heavy-duty vehicles (China VI) GB 17691
l It can support remote upgrade for TBOX OTA remote upgrade and controller like VCU/ECU
l It can support remote diagnosis, remote vehicle lock, remote vehicle control and the customized remote functions;
l It is equipped with 3 routes CAN for collection, 2 of them are high-speed CANFD;
l It can support 9-36V voltage input and can match with all vehicles in the market;
l It can support multi routes IP links and can send vehicle data to state monitoring platform and enterprise platform.
l It can provide WIFI, Bluetooth, G-Sensor collision warning and vehicle USB functions;
l The reserved hardware encrypted chip can support the symmetrical and asymmetrical encryption and digital signature;
4. Product application scope
l The product can meet the requirements of GB/T32960 new energy and the limits and measurement methods for emissions from diesel fueled heavy-duty vehicles (China VI) GB 1769. It can match new energy vehicles and heavy-duty vehicles. With the developed monitoring platform, the remote upgrade, control, vehicle lock and diagnosis of vehicles can be achieved and it can match with all vehicles models in the market.
